Metal Bracket (IR-MB07) - Dedicated for 17Lf (37, 50, 87mm stroke) Horizontal Mounting & Vertical Mounting

Product description

The IR-MB07 is metal bracket exclusively designed for the 17Lf series 37mm to 87mm strokes actuators.

Mount the servo actuator without any directional restrictions of the actuator.

• For Horizontal Mounting and Vertical Mounting
• Not compatible with 17Lf 27mm stroke version

The cross-section of the metal bracket may be sharp when assembling.

Be sure to were protective gloves.

How to Assemble

Horizontal Mounting

• Install the Bracket B Type by adding a spacer
• When installing the Bracket A Type, be sure to use the included washer.

Vertical Mounting

• Install the Bracket C Type without a spacer.
• When installing the Bracket A Type, be sure to use the included washer.
